Part Number: JM003506DPNPW01
List Price: Please contact us for pricing
Inventory: Call for stock
*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
General Information
Technical Details
Download Center
Voltage 575 V Enclosure IC01 - ODP
Frame 213/5JM Voltage 575 V Number of Poles 6 Altitude 1000 m.a.s.l. Starting Method Direct On Line Temperature Rise 80 K Insulation Class F Moment of Inertia (J) 0.8104 sq.ft.lb Breakdown Torque 260 % No Load Current 1.83 A L. R. Amperes 19.6 A Slip 2.08 % Mounting F-1 Standard NEMA MG-1 Impregnation Method Dip and Bake Polyester Terminal Block Without Painting Munsell N 1 - Matte 207N (ISO 12944 - C2) Fan Cover Material Without Fan Cover Fan Material Without fan Balancing Method 1/2 Key Overload Protector (Phenolic) Without overload protector Grease Type Mobil Polyrex EM Rotation Both (CW and CCW) Bearing Type 6209 ZZ NDE Bearing Seal Without Bearing Seal
Flange C Output 3 HP (2.2 kW) Terminal Box Left position Ambient Temperature -20°C to +40°C Duty Cycle Cont.(S1) Service Factor 1.15 Design B Locked Rotor Time 70s (cold) 39s (hot) Rated Torque 13.4 ft.lb LRC 5.9x(Code H) Rated Current 3.33 A Rated Speed 1175 rpm Frequency 60 Hz Frame Material Rolled Steel Main Terminal Box Hole 1.377" Shaft Material SAE 1040/45 Carbon Steel Grounding Lugs Single Tropicalized Painting Without Bearing Cap Yes- Bearing Cap Drip Cover Without NDE Bearing 6206 ZZ Locked Rotor Torque 210 % Noise Level 55.0 dB(A) Sealing Without Bearing Seal
