W22 Close Coupled Pump JM NEMA Premium Efficiency 2 HP 2P 143/5JM 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 2 HP 3600 2X4 TEFC 143/5JM NP W22
Brand: WEG
SKU: JM002402NPW22
Price: 623.00 CAD
Availability: InStock

Part Number: JM002402NPW22

List Price: $623.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	2 HP
RPM	3600 rpm

Voltage	230/460//380 V
Enclosure	IC411 - TEFC

Frame	143/5JM
Voltage	230/460 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.0605 sq.ft.lb
Breakdown Torque	380 %
No Load Current	2.40/1.20 A
L. R. Amperes	47.9/23.9 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 3/4"
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6206 ZZ
NDE Bearing Seal	V'Ring
