*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
60 HP
RPM
900 rpm
Voltage
460 V
Enclosure
IC411 - TEFC
Frame
404/5T
Voltage
460 V
Number of Poles
8
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
40.2 sq.ft.lb
Breakdown Torque
270 %
No Load Current
30.0 A
L. R. Amperes
475 A
Slip
2.22 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 3"
Shaft Locking Device
Without
Shaft Material
SAE 4140 Carbon Steel
Grounding Lugs
Double
Tropicalized Painting
According to IEEE-841 (96h)
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6316 C3
NDE Bearing Seal
Taconite Labyrinth
Flange
Without
Output
60 HP (45 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
23s (cold) 13s (hot)
Rated Torque
358 ft.lb
LRC
6.5x(Code H)
Rated Current
73.0 A
Rated Speed
880 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Constant Resin Flow
Terminal Block
Without
Drain
Type T, Threaded
Painting
RAL 5009 00187
Fan Cover Material
Cast Iron
Fan Material
Conductive Plastic
Balancing Method
1/2 Key
NDE Bearing
6314 C3
Locked Rotor Torque
180 %
Noise Level
60.0 dB(A)
Sealing
Taconite Labyrinth
