W22 IEEE 841 NEMA Premium Efficiency 60 HP 2P 364/5TS 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 60 HP 3600 460V TEFC 364/5TS NP W22 INPRO
Brand: WEG
SKU: IE060402W22IS
Price: 18926.00 CAD
Availability: InStock

Part Number: IE060402W22IS

List Price: $18,926.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	460 V
RPM	3600 rpm

HP	60 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	60 HP (45 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	25s (cold) 14s (hot)
Rated Torque	88.8 ft.lb
LRC	6.4x(Code G)
Rated Current	67.0 A
Rated Speed	3550 rpm
Degree of Protection	IP56
Standard	00006
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Type T, Threaded
Painting	RAL 5009 202E (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Conductive Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6314 C3
NDE Bearing Seal	Inpro/Seal
