W22 IEEE 841 NEMA Premium Efficiency 40 HP 8P 364/5T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 40 HP 900 575V TEFC 364/5T NP W22 INPRO
Brand: WEG
SKU: IE040508W22IS
Price: 23322.00 CAD
Availability: InStock

Part Number: IE040508W22IS

List Price: $23,322.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	900 rpm

HP	40 HP
Enclosure	IC411 - TEFC

Frame	364/5T
Voltage	575 V
Number of Poles	8
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	29.0 sq.ft.lb
Breakdown Torque	210 %
No Load Current	17.2 A
L. R. Amperes	240 A
Slip	2.00 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 3"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Double
Tropicalized Painting	According to IEEE-841 (96h)
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6314 C3
NDE Bearing Seal	Inpro/Seal
