W22 IEEE 841 NEMA Premium Efficiency 40 HP 6P 364/5T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 40 HP 1200 575 TEFC 364/5T NP W22 INPRO
Brand: WEG
SKU: IE040506W22IS
Price: 9551.00 CAD
Availability: InStock

Part Number: IE040506W22IS

List Price: $9,551.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	40 HP
RPM	1200 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	Without
Output	40 HP (30 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	37s (cold) 21s (hot)
Rated Torque	178 ft.lb
LRC	6.4x(Code G)
Rated Current	37.2 A
Rated Speed	1183 rpm
Degree of Protection	IP56
Standard	00006
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Type T, Threaded
Painting	RAL 5009 00187
Fan Cover Material	Cast Iron
Fan Material	Conductive Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6314 C3
NDE Bearing Seal	Inpro/Seal
