*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
25 HP
RPM
1800 rpm
Voltage
575 V
Enclosure
IC411 - TEFC
Frame
284/6TC
Voltage
575 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
5.11 sq.ft.lb
Breakdown Torque
270 %
No Load Current
8.80 A
L. R. Amperes
146 A
Slip
1.67 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1 1/2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Double
Tropicalized Painting
According to IEEE-841 (96h)
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6211 C3
Locked Rotor Torque
240 %
Noise Level
63.0 dB(A)
Sealing
Inpro/Seal
Flange
C
Output
25 HP (18.5 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
43s (cold) 24s (hot)
Rated Torque
74.2 ft.lb
LRC
6.2x(Code G)
Rated Current
23.6 A
Rated Speed
1770 rpm
Degree of Protection
IP56
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Type T, Threaded
Painting
RAL 5009 00187
Fan Cover Material
Cast Iron
Fan Material
Conductive Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6311 C3
NDE Bearing Seal
Inpro/Seal
