*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
25 HP
RPM
1800 rpm
Voltage
460 V
Enclosure
IC411 - TEFC
Frame
284/6T
Voltage
460 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
5.11 sq.ft.lb
Breakdown Torque
270 %
No Load Current
11.0 A
L. R. Amperes
183 A
Slip
1.67 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1 1/2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Double
Tropicalized Painting
According to IEEE-841 (96h)
Bearing Cap
Yes- Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6311 C3
NDE Bearing Seal
Inpro/Seal
Flange
Without
Output
25 HP (18.5 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
43s (cold) 24s (hot)
Rated Torque
74.2 ft.lb
LRC
6.2x(Code G)
Rated Current
29.5 A
Rated Speed
1770 rpm
Degree of Protection
IP56
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Type T, Threaded
Painting
RAL 5009 202E (ISO 12944 - C4)
Fan Cover Material
Cast Iron
Fan Material
Conductive Plastic
Drip Cover
Without
NDE Bearing
6211 C3
Locked Rotor Torque
240 %
Noise Level
63.0 dB(A)
Sealing
Inpro/Seal
