W22 IEEE 841 NEMA Premium Efficiency 7.5 HP 8P 254/6T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 900 460V TEFC 254/6T NP W22 INPRO
Brand: WEG
SKU: IE007408W22IS
Price: 8062.00 CAD
Availability: InStock

Part Number: IE007408W22IS

List Price: $8,062.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	460 V
RPM	900 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	7.5 HP (5.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	59s (cold) 33s (hot)
Rated Torque	44.8 ft.lb
LRC	5.3x(Code G)
Rated Current	11.1 A
Rated Speed	880 rpm
Degree of Protection	IP56
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Type T, Threaded
Painting	RAL 5009 00187
Fan Cover Material	Cast Iron
Fan Material	Conductive Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	Inpro/Seal
