W22 IEEE 841 NEMA Premium Efficiency 7.5 HP 2P 213/5T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 3600 460 TEFC 213/5T NP W22 INPRO
Brand: WEG
SKU: IE007402W22IS
Price: 3450.00 CAD
Availability: InStock

Part Number: IE007402W22IS

List Price: $3,450.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	460 V
RPM	3600 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	7.5 HP (5.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	39s (cold) 22s (hot)
Rated Torque	11.2 ft.lb
LRC	7.2x(Code H)
Rated Current	8.97 A
Rated Speed	3525 rpm
Degree of Protection	IP56
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Type T, Threaded
Painting	RAL 5009 202E (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Conductive Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 C3
NDE Bearing Seal	Inpro/Seal
