W22 IEEE 841 NEMA Premium Efficiency 5 HP 6P 213/5T 3Ph 200 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 5 HP 1200 200V TEFC 213/5T IE841 INPRO
Brand: WEG
SKU: IE005206W22IS
Price: 1.00 CAD
Availability: InStock

Part Number: IE005206W22IS

List Price: Please contact us for pricing

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	5 HP
RPM	1200 rpm

Voltage	200 V
Enclosure	IC411 - TEFC

Flange	Without
Output	5 HP (3.7 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	102s (cold) 57s (hot)
Rated Torque	22.4 ft.lb
LRC	6.8x(Code J)
Rated Current	15.7 A
Rated Speed	1170 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Type T, Threaded
Painting	RAL 5009 202E (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Conductive Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 C3
NDE Bearing Seal	Inpro/Seal
