W21 Explosion-proof Motor NEMA Premium Efficiency 200 HP 6P 447T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 200HP 1200 2X4 XP 447T NP RB
Brand: WEG
SKU: HX200406NPRB447T
Price: 68180.00 CAD
Availability: InStock

Part Number: HX200406NPRB447T

List Price: $68,180.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	1200 rpm

HP	200 HP
Enclosure	IC411 - TEFC

Frame	447T
Voltage	230/460 V
Number of Poles	6
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	134 sq.ft.lb
Breakdown Torque	280 %
No Load Current	250/125 A
L. R. Amperes	3884/1942 A
Slip	0.83 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	2xNPT 3"
Shaft Locking Device	With
Shaft Material	SAE 4140 Carbon Steel
Grounding Lugs	Double
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	NU-319 C3
NDE Bearing Seal	Viton Seal
