W21 Explosion-proof Motor NEMA Premium Efficiency 100 HP 4P 404/5T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 100HP 1800 2X4 XP 3 405T NP BB W21X
Brand: WEG
SKU: HX100404NPBBW21X
Price: 14517.00 CAD
Availability: InStock

Part Number: HX100404NPBBW21X

List Price: $14,517.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	100 HP
RPM	1800 rpm

Voltage	230/460//380 V
Enclosure	IC411 - TEFC

Flange	Without
Output	100 HP (75 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	23s (cold) 13s (hot)
Rated Torque	40.8 kgfm
LRC	7.2x(Code H)
Rated Current	226/113 A
Rated Speed	1780 rpm
Degree of Protection	IP55
Standard	NEMA MG-1
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Sinterized, Exd
Painting	RAL 5009 202P (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Aluminum
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6217 C3
NDE Bearing Seal	Lip Seal
