W21 Explosion-proof Motor NEMA Premium Efficiency 1.5 HP 6P 182/4T 3Ph 230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 1.5HP 1200 2X4 XP 182/4T NP W21X
Brand: WEG
SKU: HX001406NPW21X
Price: 2380.00 CAD
Availability: InStock

Part Number: HX001406NPW21X

List Price: $2,380.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460 V
RPM	1200 rpm

HP	1.5 HP
Enclosure	IC411 - TEFC

Frame	182/4T
Voltage	230/460 V
Number of Poles	6
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.4212 sq.ft.lb
Breakdown Torque	330 %
No Load Current	2.80/1.40 A
L. R. Amperes	30.6/15.3 A
Slip	2.92 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 3/4"
Shaft Locking Device	Without
Painting	RAL 5009 202P (ISO 12944 - C4)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6307 2RS
NDE Bearing Seal	Lip Seal
