W22 NEMA Premium Efficiency 350 HP 6P 586/7T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 350HP 1200 575 TEFC 586/7T NP W22 RB
Brand: WEG
SKU: HT350506NPRBW22
Price: 48421.00 CAD
Availability: InStock

Part Number: HT350506NPRBW22

List Price: $48,421.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	350 HP
RPM	1200 rpm

Voltage	575 V
Enclosure	IC411 - TEFC

Flange	Without
Output	350 HP (260 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	52s (cold) 29s (hot)
Rated Torque	1540 ft.lb
LRC	6.0x(Code G)
Rated Current	337 A
Rated Speed	1192 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	NU-322 C3
NDE Bearing Seal	Taconite Labyrinth
