*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
20 HP
RPM
900 rpm
Voltage
575 V
Enclosure
IC411 - TEFC
Frame
324/6T
Voltage
575 V
Number of Poles
8
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
9.37 sq.ft.lb
Breakdown Torque
220 %
No Load Current
12.8 A
L. R. Amperes
113 A
Slip
2.22 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6312 C3
NDE Bearing Seal
V'Ring
Flange
Without
Output
20 HP (15 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
48s (cold) 27s (hot)
Rated Torque
119 ft.lb
LRC
5.0x(Code G)
Rated Current
22.6 A
Rated Speed
880 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6212 C3
Locked Rotor Torque
190 %
Noise Level
56.0 dB(A)
Sealing
V'Ring
