*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
15 HP
RPM
3600 rpm
Voltage
575 V
Enclosure
IC411 - TEFC
Frame
213/5T
Voltage
575 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.6362 sq.ft.lb
Breakdown Torque
280 %
No Load Current
4.64 A
L. R. Amperes
107 A
Slip
2.22 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Drip Cover
Without
NDE Bearing
6207 ZZ
Locked Rotor Torque
240 %
Noise Level
68.0 dB(A)
Sealing
V'Ring
Flange
Without
Output
15 HP (11 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
A
Locked Rotor Time
21s (cold) 12s (hot)
Rated Torque
22.4 ft.lb
LRC
7.9x(Code J)
Rated Current
13.6 A
Rated Speed
3520 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6308 ZZ
NDE Bearing Seal
V'Ring
