HP
15 HP
RPM
3600 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
254/6T
Voltage
230/460 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
1.26 sq.ft.lb
Breakdown Torque
270 %
No Load Current
10.6/5.30 A
L. R. Amperes
231/116 A
Slip
1.89 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1 1/2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6209 C3
Locked Rotor Torque
220 %
Noise Level
72.0 dB(A)
Sealing
V'Ring
Flange
Without
Output
15 HP (11 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
36s (cold) 20s (hot)
Rated Torque
22.3 ft.lb
LRC
6.7x(Code G)
Rated Current
34.5/17.2 A
Rated Speed
3532 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6309 C3
NDE Bearing Seal
V'Ring
