W22 NEMA Premium Efficiency 3 HP 4P 182/4T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 3 HP 1800 575 TEFC 182/4T NP W22
Brand: WEG
SKU: HT003504NPW22
Price: 1204.00 CAD
Availability: InStock

Part Number: HT003504NPW22

List Price: $1,204.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	575 V
RPM	1800 rpm

HP	3 HP
Enclosure	IC411 - TEFC

Frame	182/4T
Voltage	575 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.3401 sq.ft.lb
Breakdown Torque	330 %
No Load Current	1.60 A
L. R. Amperes	25.3 A
Slip	2.22 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6207 ZZ
NDE Bearing Seal	V'Ring
