ELECTRIC MOTOR THREE PHASE 2 HP 02 143/5T 575 C/W 6 leads WCF2 60Hz F-1/B3R(D) IP55 NEMA PREMIUM EFFICIENCY ROLLED STEEL IHP

Name: 2 HP 3600 575 TEFC 143/5T NP W01
Brand: WEG
SKU: HT002502NPW01
Price: 417.00 CAD
Availability: InStock

Part Number: HT002502NPW01

List Price: $417.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

HP	2 HP
RPM	3600 rpm

Voltage	575V
Enclosure	IC411 - TEFC

Flange	Without
Output	2 HP (1.5 kW)
Terminal Box	Left position
Application	ROLLED STEEL
Power	2 HP
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.1279 sq.ft.lb
Breakdown Torque	300 %
No Load Current	0.850 A
L. R. Amperes	19.6 A
Slip	2.22 %
Mounting	F-1/B3R(D)
Frequency	60 Hz
Frame Material	Rolled Steel
Main Terminal Box Hole	1.118"
Drain	Rubber, automatic
Painting	Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material	Industrial polymer
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6205 ZZ
NDE Bearing Seal	Without Bearing Seal
