*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
2 HP
RPM
900 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
213/5T
Voltage
230/460 V
Number of Poles
8
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
1.79 sq.ft.lb
Breakdown Torque
290 %
No Load Current
4.60/2.30 A
L. R. Amperes
46.8/23.4 A
Slip
2.78 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6308 ZZ
NDE Bearing Seal
V'Ring
Flange
Without
Output
2 HP (1.5 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
70s (cold) 39s (hot)
Rated Torque
12.0 ft.lb
LRC
6.9x(Code L)
Rated Current
6.78/3.39 A
Rated Speed
875 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6207 ZZ
Locked Rotor Torque
220 %
Noise Level
52.0 dB(A)
Sealing
V'Ring
