W22 NEMA Premium Efficiency 1 HP 6P 143/5T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 1 HP 1200 2X4 TEFC 143/5T NP W22
Brand: WEG
SKU: HT000406NPW22
Price: 1010.00 CAD
Availability: InStock

Part Number: HT000406NPW22

List Price: $1,010.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	230/460//380 V
RPM	1200 rpm

HP	1 HP
Enclosure	IC411 - TEFC

Flange	Without
Output	1 HP (0.75 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	50s (cold) 28s (hot)
Rated Torque	4.53 ft.lb
LRC	6.2x(Code K)
Rated Current	3.46/1.73 A
Rated Speed	1160 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6205 ZZ
NDE Bearing Seal	V'Ring
