HP
3 HP
RPM
3600 rpm
Voltage
115/208-230 V
Enclosure
IC411 - TEFC
Frame
56HC
Voltage
115/208-230 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.0944 sq.ft.lb
Breakdown Torque
280 %
No Load Current
8.00/3.45-4.00 A
L. R. Amperes
205/112-102 A
Slip
2.78 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Rolled Steel
Main Terminal Box Hole
0.881"
Drain
Rubber, automatic
Painting
Munsell N 1 - Matte 207N (ISO 12944 - C2)
Fan Cover Material
Industrial polymer
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6204 ZZ
NDE Bearing Seal
Without Bearing Seal
Flange
C
Output
3 HP (2.2 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.15 (1.00 @ 208V)
Design
L
Locked Rotor Time
12s (cold) 7s (hot)
Rated Torque
4.50 ft.lb
LRC
8.2x(Code J)
Rated Current
25.0/13.6-12.5 A
Rated Speed
3500 rpm
Degree of Protection
IP55
Standard
NEMA MG-1
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6202 ZZ
Locked Rotor Torque
220 %
Noise Level
68.0 dB(A)
Sealing
V'Ring
