*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
30 HP
RPM
1800 rpm
Voltage
575 V
Enclosure
IC411 - TEFC
Frame
284/6TD
Voltage
575 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
5.85 sq.ft.lb
Breakdown Torque
240 %
No Load Current
9.84 A
L. R. Amperes
171 A
Slip
1.67 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1 1/2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6211 C3
Locked Rotor Torque
240 %
Noise Level
63.0 dB(A)
Sealing
V'Ring
Flange
D
Output
30 HP (22 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
36s (cold) 20s (hot)
Rated Torque
89.0 ft.lb
LRC
6.1x(Code G)
Rated Current
28.1 A
Rated Speed
1770 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6311 C3
NDE Bearing Seal
V'Ring
