ELECTRIC MOTOR THREE PHASE 75 HP 04 364/5TC 208-230/460//380 C/W 12 cables 60Hz B34R(D) IP55 EXPLOSION PROOF NEMA PREMIUM EFFICIENCY WFX1

Name: 75 HP 1800 2X4 XP 3 364/5TC NP W21X
Brand: WEG
SKU: CX075404NPW21X
Price: 25240.00 CAD
Availability: InStock

Part Number: CX075404NPW21X

List Price: $25,240.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460//380V
RPM	1800 rpm

HP	75 HP
Enclosure	IC411 - TEFC

Frame	364/5T
Voltage	230/460 V
Number of Poles	4
Class	ELECTRIC MOTOR
Detail	NEMA PREMIUM EFFICIENCY
Polarity	04
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	A
Locked Rotor Time	28s (cold) 16s (hot)
Rated Torque	221 ft.lb
LRC	7.7x(Code H)
Rated Current	166/83.2 A
Rated Speed	1782 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Constant Resin Flow
Terminal Block	Without
Drain	Sinterized, Exd
Painting	RAL 5009 202P (ISO 12944 - C4)
Fan Cover Material	Cast Iron
Fan Material	Aluminum
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6314 C3
NDE Bearing Seal	Lip Seal
