W21 Explosion-proof Motor NEMA Premium Efficiency 30 HP 4P 286TC 3Ph 208-230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 30 HP 1800 2X4 XP 286TC NP W21X
Brand: WEG
SKU: CX030404NPW21X
Price: 9250.00 CAD
Availability: InStock

Part Number: CX030404NPW21X

List Price: $9,250.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460//380 V
RPM	1800 rpm

HP	30 HP
Enclosure	IC411 - TEFC

Flange	C
Output	30 HP (22 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	30s (cold) 17s (hot)
Rated Torque	89.0 ft.lb
LRC	6.1x(Code G)
Rated Current	79.6-72.0/36.0 A
Rated Speed	1770 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Sinterized, Exd
Painting	RAL 5009 00186
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 C3
NDE Bearing Seal	Lip Seal
