W21 Explosion-proof Motor NEMA Premium Efficiency 20 HP 2P 256TC 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 20 HP 3600 2X4 XP 3 256TC NP W21X
Brand: WEG
SKU: CX020402NPW21X
Price: 6788.00 CAD
Availability: InStock

Part Number: CX020402NPW21X

List Price: $6,788.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	3600 rpm

HP	20 HP
Enclosure	IC411 - TEFC

Flange	C
Output	20 HP (15 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.15
Design	B
Locked Rotor Time	46s (cold) 26s (hot)
Rated Torque	29.8 ft.lb
LRC	6.2x(Code G)
Rated Current	46.4/23.2 A
Rated Speed	3530 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Sinterized, Exd
Painting	RAL 5009 00186
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	Lip Seal
