W21 Explosion-proof Motor NEMA Premium Efficiency 10 HP 2P 213/5TC 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 10 HP 3600 2X4 XP 213/5TC NP W21X
Brand: WEG
SKU: CX010402NPW21X
Price: 4534.00 CAD
Availability: InStock

Part Number: CX010402NPW21X

List Price: $4,534.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	230/460//380 V
RPM	3600 rpm

HP	10 HP
Enclosure	IC411 - TEFC

Frame	213/5TC
Voltage	230/460 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.5512 sq.ft.lb
Breakdown Torque	280 %
No Load Current	7.20/3.60 A
L. R. Amperes	161/80.7 A
Slip	2.08 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1"
Shaft Locking Device	Without
Painting	RAL 5009 202P (ISO 12944 - C4)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6308 2RS
NDE Bearing Seal	Lip Seal
