Rated operational current
400 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWM
Control voltage
440-575V 50/60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
1000 V
Rated operational frequency - minimum
50 Hz
Mechanical lifespan (AC)
5 million
Elecctrical lifespan
0.5 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
520 A
Rated operational voltage Ue - UL/CSA
600 V
Width
209 mm (8.23 in)
Weight
11.667 kg
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
60 Hz
Mechanical lifespan (DC)
5 million
Degree of protection IP (IEC 60529) - Main circuit
IP00
Rated current In - AC-4
300 A
Rated operational voltage
690 V
Height
243 mm (9.57 in)
Depth
200,7 mm (7.90 in)
