Rated operational current
250 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWM
Control voltage
24-28V 50/60Hz-DC
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
1000 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
1 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
350 A
Rated operational voltage Ue - UL/CSA
600 V
Width
144 mm (5.67 in)
Weight
6.745 kg
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
10 million
Degree of protection IP (IEC 60529) - Main circuit
IP00
Rated current In - AC-4
110 A
Rated operational voltage
1000 V
Height
200 mm (7.87 in)
Depth
181 mm (7.13 in)
