*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
Rated operational current
12 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWM
Control voltage
180-208V 50Hz/208-240V 60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
1000 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
1,5 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
25 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
300 g
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
12 million
Degree of protection IP (IEC 60529) - Main circuit
IP20
Rated current In - AC-4
7 A
Rated operational voltage
690 V
Height
81 mm (3.19 in)
Depth
87 mm (3.43 in)
