Rated operational current
22 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWC0
Control voltage
180-208V 50Hz/208-240V 60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
690 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
3 million
Elecctrical lifespan
0,6 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
32 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
202 g
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
Not available
Degree of protection IP (IEC 60529) - Main circuit
IP20
Rated current In - AC-4
9 A
Rated operational voltage
690 V
Height
58,1 mm (2.29 in)
Depth
56 mm (2.20 in)
