Rated operational current
12 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWC0
Control voltage
110V 50Hz/120V 60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
690 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
1,2 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
22 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
194 g
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
12 million
Degree of protection IP (IEC 60529) - Main circuit
IP20
Rated current In - AC-4
4,5 A
Rated operational voltage
690 V
Height
58 mm (2.28 in)
Depth
52 mm (2.05 in)
