*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
Rated operational current
9 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWBS
Control voltage
24V 50/60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
690 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
2 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
25 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
0.433 kg
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
10 million
Degree of protection IP (IEC 60529) - Main circuit
IP10
Rated current In - AC-4
4,4 A
Rated operational voltage
690 V
Height
78,4 mm (3.09 in)
Depth
125.8 mm (4.95 in)
