Rated operational current
32 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWBS
Control voltage
24V DC
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
690 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
1.6 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
50 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
600 g
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
10 million
Degree of protection IP (IEC 60529) - Main circuit
IP10
Rated current In - AC-4
13,7 A
Rated operational voltage
690 V
Height
85 mm (3.35 in)
Depth
141.1 mm (5.56 in)
