*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
Rated operational current
25 A (N1)
Main contacts
3 NO
Terminal type
Screw
Reference
CWBN
Control voltage
120V 50/60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
690 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
10 million
Elecctrical lifespan
1.6 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
110 A
Rated operational voltage Ue - UL/CSA
600 V
Width
45 mm (1.77 in)
Weight
525 g
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
10 million
Degree of protection IP (IEC 60529) - Main circuit
IP10
Rated current In - AC-4
26 A
Rated operational voltage
690 V
Height
85 mm (3.35 in)
Depth
102,2 mm (4.02 in)
