*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
Rated operational current
95 A
Main contacts
3 NO
Terminal type
Screw
Reference
CWB
Control voltage
120V 50/60Hz
Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1
1000 V
Rated operational frequency - minimum
25 Hz
Mechanical lifespan (AC)
6 million
Elecctrical lifespan
1.1 million
Degree of protection IP (IEC 60529) - Control circuit
IP20
Rated operational Current Ie AC-1 (¿ = 55 ºC)
140 A
Rated operational voltage Ue - UL/CSA
600 V
Width
72 mm (2.834 in)
Weight
1.6 kg
Rated insulation voltage Ui (pollution degree 3) - UL, CSA
600 V
Rated operational frequency - maximum
400 Hz
Mechanical lifespan (DC)
6 million
Degree of protection IP (IEC 60529) - Main circuit
IP10
Rated current In - AC-4
52 A
Rated operational voltage
1000 V
Height
149 mm (5.87 in)
Depth
144 mm (5.67 in)
