*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
100 HP
RPM
1200 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
444/5TC
Voltage
230/460 V
Number of Poles
6
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
87.3 sq.ft.lb
Breakdown Torque
250 %
No Load Current
90.0/45.0 A
L. R. Amperes
1498/749 A
Slip
0.92 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
2xNPT 3"
Shaft Locking Device
Without
Shaft Material
SAE 4140 Carbon Steel
Grounding Lugs
Double
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6316 C3
Locked Rotor Torque
220 %
Noise Level
69.0 dB(A)
Sealing
WSeal
Flange
C
Output
100 HP (75 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
36s (cold) 20s (hot)
Rated Torque
442 ft.lb
LRC
6.2x(Code G)
Rated Current
242/121 A
Rated Speed
1189 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Constant Resin Flow
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6319 C3
NDE Bearing Seal
WSeal
