*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
40 HP
RPM
1200 rpm
Voltage
575 V
Enclosure
IC411 - TEFC
Frame
364/5TC
Voltage
575 V
Number of Poles
6
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
21.8 sq.ft.lb
Breakdown Torque
240 %
No Load Current
13.2 A
L. R. Amperes
238 A
Slip
1.42 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 3"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Double
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6314 C3
NDE Bearing Seal
Oil Seal
Flange
C
Output
40 HP (30 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
37s (cold) 21s (hot)
Rated Torque
178 ft.lb
LRC
6.4x(Code G)
Rated Current
37.2 A
Rated Speed
1183 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Constant Resin Flow
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6314 C3
Locked Rotor Torque
200 %
Noise Level
66.0 dB(A)
Sealing
Oil Seal
