W22 Super Premium Efficiency 30 HP 4P 284/6TC 3Ph 208-230/460 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 30 HP 1800 2X4V TEFC 284/6TC SUPER W22
Brand: WEG
SKU: CT030404SPW22
Price: 8298.00 CAD
Availability: InStock

Part Number: CT030404SPW22

List Price: $8,298.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	208-230/460 V
RPM	1800 rpm

HP	30 HP
Enclosure	IC411 - TEFC

Flange	C
Output	30 HP (22 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	A
Locked Rotor Time	45s (cold) 25s (hot)
Rated Torque	88.8 ft.lb
LRC	8.0x(Code J)
Rated Current	78.7-71.2/35.6 A
Rated Speed	1775 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 6002 203A (ISO 12944 - C3)
Fan Cover Material	Cast Iron
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6311 C3
NDE Bearing Seal	V'Ring
