*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
20 HP
RPM
1200 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
284/6TC
Voltage
230/460 V
Number of Poles
6
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
9.16 sq.ft.lb
Breakdown Torque
260 %
No Load Current
19.0/9.50 A
L. R. Amperes
300/150 A
Slip
2.08 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1 1/2"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
Yes- Bearing Cap
Drip Cover
Without
NDE Bearing
6211 C3
Locked Rotor Torque
229 %
Noise Level
59.0 dB(A)
Sealing
V'Ring
Flange
C
Output
20 HP (15 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
28s (cold) 16s (hot)
Rated Torque
89.4 ft.lb
LRC
6.2x(Code G)
Rated Current
48.4/24.2 A
Rated Speed
1175 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 203A (ISO 12944 - C3)
Fan Cover Material
Cast Iron
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6311 C3
NDE Bearing Seal
V'Ring
