W22 NEMA Premium Efficiency 7.5 HP 8P 254/6TC 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 900 575 TEFC 254/6TC NP W22
Brand: WEG
SKU: CT007508NPW22
Price: 5910.00 CAD
Availability: InStock

Part Number: CT007508NPW22

List Price: $5,910.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	900 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Frame	254/6TC
Voltage	575 V
Number of Poles	8
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	4.43 sq.ft.lb
Breakdown Torque	250 %
No Load Current	5.20 A
L. R. Amperes	47.1 A
Slip	2.22 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 1 1/2"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	Yes- Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6309 C3
NDE Bearing Seal	V'Ring
