W22 NEMA Premium Efficiency 7.5 HP 2P 182/4TC 3Ph 208-230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 7.5HP 3600 2X4V TEFC 182/4TC NP W22
Brand: WEG
SKU: CT007402NPW22184T
Price: 1794.00 CAD
Availability: InStock

Part Number: CT007402NPW22184T

List Price: $1,794.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	208-230/460//380 V
RPM	3600 rpm

HP	7.5 HP
Enclosure	IC411 - TEFC

Flange	C
Output	7.5 HP (5.5 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	A
Locked Rotor Time	30s (cold) 17s (hot)
Rated Torque	11.3 ft.lb
LRC	8.2x(Code J)
Rated Current	17.5/8.76 A
Rated Speed	3485 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6207 ZZ
NDE Bearing Seal	V'Ring
