HP
3 HP
RPM
1200 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
213/5TC
Voltage
230/460 V
Number of Poles
6
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
1.20 sq.ft.lb
Breakdown Torque
270 %
No Load Current
5.10/2.55 A
L. R. Amperes
61.7/30.9 A
Slip
2.08 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 1"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6308 ZZ
NDE Bearing Seal
V'Ring
Flange
C
Output
3 HP (2.2 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
104s (cold) 58s (hot)
Rated Torque
13.4 ft.lb
LRC
7.0x(Code K)
Rated Current
8.82/4.41 A
Rated Speed
1175 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6207 ZZ
Locked Rotor Torque
190 %
Noise Level
55.0 dB(A)
Sealing
V'Ring
