*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
3 HP
RPM
3600 rpm
Voltage
208-230/460//380 V
Enclosure
IC411 - TEFC
Frame
143/5TC
Voltage
230/460 V
Number of Poles
2
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.0605 sq.ft.lb
Breakdown Torque
360 %
No Load Current
2.60/1.30 A
L. R. Amperes
60.1/30.1 A
Slip
3.89 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 3/4"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Drip Cover
Without
NDE Bearing
6204 ZZ
Locked Rotor Torque
330 %
Noise Level
68.0 dB(A)
Sealing
V'Ring
Flange
C
Output
3 HP (2.2 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
25s (cold) 14s (hot)
Rated Torque
4.55 ft.lb
LRC
8.1x(Code J)
Rated Current
7.42/3.71 A
Rated Speed
3460 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Balancing Method
1/2 Key
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6205 ZZ
NDE Bearing Seal
V'Ring
