W22 NEMA Premium Efficiency 2 HP 2P 143/5TC 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Name: 2 HP 3600 2X4 TEFC 143/5TC NP W22
Brand: WEG
SKU: CT002402NPW22
Price: 1164.00 CAD
Availability: InStock

Part Number: CT002402NPW22

List Price: $1,164.00

Quantity:

Request Different Configuration

Inventory: In stock

Voltage	230/460//380 V
RPM	3600 rpm

HP	2 HP
Enclosure	IC411 - TEFC

Frame	143/5TC
Voltage	230/460 V
Number of Poles	2
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.0605 sq.ft.lb
Breakdown Torque	380 %
No Load Current	2.40/1.20 A
L. R. Amperes	47.9/23.9 A
Slip	2.78 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 3/4"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6205 ZZ
NDE Bearing Seal	V'Ring
