*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)
HP
1.5 HP
RPM
1800 rpm
Voltage
230/460//380 V
Enclosure
IC411 - TEFC
Frame
145TC
Voltage
230/460 V
Number of Poles
4
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Temperature Rise
80 K
Insulation Class
F
Moment of Inertia (J)
0.1431 sq.ft.lb
Breakdown Torque
350 %
No Load Current
2.20/1.10 A
L. R. Amperes
33.9/17.0 A
Slip
2.50 %
Mounting
F-1
Frequency
60 Hz
Frame Material
Cast Iron
Main Terminal Box Hole
NPT 3/4"
Shaft Locking Device
Without
Shaft Material
SAE 1040/45 Carbon Steel
Grounding Lugs
Single
Tropicalized Painting
Without
Bearing Cap
No-Without Bearing Cap
Overload Protector (Phenolic)
Without overload protector
Grease Type
Mobil Polyrex EM
Rotation
Both (CW and CCW)
Bearing Type
6205 ZZ
NDE Bearing Seal
V'Ring
Flange
C
Output
1.5 HP (1.1 kW)
Terminal Box
Left position
Ambient Temperature
-20°C to +40°C
Duty Cycle
Cont.(S1)
Service Factor
1.25
Design
B
Locked Rotor Time
25s (cold) 14s (hot)
Rated Torque
4.49 ft.lb
LRC
8.4x(Code L)
Rated Current
4.04/2.02 A
Rated Speed
1755 rpm
Degree of Protection
IP55
Standard
00006
Impregnation Method
Dip and Bake Polyester
Terminal Block
Without
Drain
Rubber, automatic
Painting
RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material
Steel
Fan Material
Plastic
Drip Cover
Without
NDE Bearing
6204 ZZ
Locked Rotor Torque
290 %
Noise Level
51.0 dB(A)
Sealing
V'Ring
