W22 NEMA Premium Efficiency 1 HP 8P 182/4TC 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 1 HP 900 575 TEFC 182/4TC NP W22
Brand: WEG
SKU: CT000508NPW22
Price: 2110.00 CAD
Availability: InStock

Part Number: CT000508NPW22

List Price: $2,110.00

Quantity:

Request Different Configuration

Inventory: Low Inventory

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	575 V
RPM	900 rpm

HP	1 HP
Enclosure	IC411 - TEFC

Flange	C
Output	1 HP (0.75 kW)
Terminal Box	Left position
Ambient Temperature	-20°C to +40°C
Duty Cycle	Cont.(S1)
Service Factor	1.25
Design	B
Locked Rotor Time	39s (cold) 22s (hot)
Rated Torque	5.97 ft.lb
LRC	6.3x(Code N)
Rated Current	1.85 A
Rated Speed	880 rpm
Degree of Protection	IP55
Standard	00006
Impregnation Method	Dip and Bake Polyester
Terminal Block	Without
Drain	Rubber, automatic
Painting	RAL 5009 207A (ISO 12944 - C3)
Fan Cover Material	Steel
Fan Material	Plastic
Balancing Method	1/2 Key
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6207 ZZ
NDE Bearing Seal	V'Ring
