W22 NEMA Premium Efficiency 1 HP 4P 143TC 3Ph 380 V 60 Hz IC411 - TEFC - Foot-mounted

Name: 1 HP 1800 380 TEFC 143TC NP W22
Brand: WEG
SKU: CT000304NPW22
Price: 1096.00 CAD
Availability: InStock

Part Number: CT000304NPW22

List Price: $1,096.00

Quantity:

Request Different Configuration

Inventory: Call for stock

*Product may be available, please contact us for more details. 1-877-PAMENSKY (7263675)

Voltage	380 V
RPM	1800 rpm

HP	1 HP
Enclosure	IC411 - TEFC

Frame	143TC
Voltage	380 V
Number of Poles	4
Altitude	1000 m.a.s.l.
Starting Method	Direct On Line
Temperature Rise	80 K
Insulation Class	F
Moment of Inertia (J)	0.1172 sq.ft.lb
Breakdown Torque	350 %
No Load Current	1.14 A
L. R. Amperes	15.3 A
Slip	2.22 %
Mounting	F-1
Frequency	60 Hz
Frame Material	Cast Iron
Main Terminal Box Hole	NPT 3/4"
Shaft Locking Device	Without
Shaft Material	SAE 1040/45 Carbon Steel
Grounding Lugs	Single
Tropicalized Painting	Without
Bearing Cap	No-Without Bearing Cap
Overload Protector (Phenolic)	Without overload protector
Grease Type	Mobil Polyrex EM
Rotation	Both (CW and CCW)
Bearing Type	6205 ZZ
NDE Bearing Seal	V'Ring
